Kammprofile Gasket Machine
The Kammprofile Gasket Machine by Kaxite Seals revolutionizes industrial sealing solutions with unmatched precision and durability. Ideal for engineers and manufacturers, this advanced machine ensures leak-free performance in high-pressure environments, significantly reducing downtime and maintenance costs. Its innovative design and robust construction set it apart from competitors, delivering reliable results that enhance operational efficiency. Experience the confidence of superior sealing technology – invest in Kaxite Seals for lasting quality.
Send Inquiry
Product Description
| Specification as following: | |
| STYLE |
KXT E1300 Kammprofile gasket machine |
| Gasket thickness | 3 -- 4mm |
| Gasket width | 10--50mm |
| Maximum gasket OD | 4000mm |
| Minimum gasket ID | 280mm |
| type of tooth | 1.5mm or 1.0mm pitch tooth, or wave tooth |
| Total power | 4kw |
| Spindle motor power | 1.5kw |
| Spindle speed | 0--1200 rpm |
| Feed motor power | 0.4kw |
| Feed linear speed | 0--20mm/s |
| Frequency Converter | 2.2G 0.4G |
| Power supply voltage | 380V/220V, 3phases, for option |
| Air compressor | 0.6-0.8 MPA |
| Machine measurement | 800*1000*1360mm |
| Machine net weight | 500kg |
